Vulcan K20ETT 20 Gallon Tilting 2/3 Steam Jacketed Electric Kettle
| Ship Weight | 225 LB |
| Manufacturer | Vulcan |
| Model Number | K20ETT |
| Manufacturer Part # | K20ETT |
| Hazardous Materials | No |
| Oversized Shipping | No |
| Dimensions (HxWxD) | 53-1/2" x 35-3/4" x 25-3/4" |
| Spatial Orientation | Floor Model |
| Capacity | 20 Gal. |
| Kettle Jacket | 2/3 |
| Max PSI | 50 |
| Tilting | Yes |
| Power | Electric |
| Electrical | 208v/60/3ph |
| Convertible to 240 Volts | Yes |
| Convertible to Single Phase | Yes |
| Default Amps | 33 |
| Wattage | 12 kW |
| UL Listed | Yes |
| NSF Listed | No |
The K20ETT is a Tilting Steam Kettle from Vulcan that runs on Electricity. This countertop kettle is constructed of stainless steel , including a 316 series steel liner, and is 2/3 jacketed. Capacity is 20 gallons. The jacket contains water, antifreeze, and rust inhibitor; offering protection to 30° below zero. The removable elements are field reversible. A mounting base includes lugs, which can be used to bolt the product to either a counter or floor stand. The tilt handle is located on the right side and features an insulated pull knob. The tilt lock can tilt up to 100°.
The various controls include solid state temperature control (with warm, simmer, and boil settings), a vacuum/pressure gauge, and a pressure relief valve. A light, and eventually a shut-off, will occur when water is low. The controls, as well as the faucet bracket, are in an enclosure to protect from water. This unit is shipped 208v/60/3ph, but can be field converted to 208v/60/1ph, 240v/60/1ph, or 240v/60/3ph. It UL listed, and meets NSF Standard #4.
Vulcan K20ETT Features
- Tilting Kettle
- Material: Stainless Steel
- Counter
- Capacity: 20 Gallons
- Electric
- 2/3 Jacketed
- Draw Off Valve w/Perforated Strainer
- Faucet Bracket
- Bar Rim w/Pouring Lip
- Embossed Gallon/Liter Markings
- 316 Series Stainless Steel Liner
- Mounting Base
- Removable Electrical Elements
- Tilt Handle w/Insulated Pull Knob
- Low Water Light & Shut-Off
- Water Resistant Controls
- Electrical: 208v/60/3ph
- Field Convertible to Single Phase and/or 240 Volt
- UL Listed
Vulcan K20ETT Benefits
- In order to prevent oxidation, a rust inhibitor is a part of the jackets make-up
- Antifreeze protects the kettle to 30°F below zero
- Embossed measurement markings makes it easy to see how much you have within the kettle
- A bracket makes it possible to attach an optional water faucet
- Mounting base guarantees that the kettle can be bolted to counter tops or floor stands
- Removable electric elements are serviceable for added longevity
Overall Dimensions:
Height: 53 1/2"
Width: 35 3/4"
Depth: 25 3/4"
