The Structural Concepts NR7247RSV Reveal® Service Refrigerated Case is a freestanding, commercial-grade display refrigeration unit designed for full-service foodservice environments. Featuring a 71-3/4" width and 47-1/4" height, this See-thru refrigerated display case integrates self-contained Breeze-E (Type II) refrigeration with EnergyWise technology for energy-efficient operation. Constructed with UV-coated, frameless glass fronts and sides, it ensures optimal product presentation while maintaining durability under high-traffic conditions. Equipped with two removable and adjustable clear glass shelves, LED lighting at the top and on shelves enhances visibility naturally, supporting effective merchandising in retail or restaurant settings. Its full end panels and rear sliding glass doors provide streamlined access for restocking and maintenance, making it suitable for busy foodservice environments requiring reliable, clean refrigeration solutions with precise temperature control.
Structural Concepts NR7247RSV Features
The Reveal® Service Refrigerated Case offers a robust design with (2) adjustable clear glass shelves, an energy-efficient self-contained Breeze-E (Type II) refrigeration system, and UV-coated, frameless glass for enhanced product visibility. Its freestanding structure simplifies installation in various commercial kitchens, retail shops, and fast-casual outlets. Designed for medium-volume foodservice workflows, it supports quick product access with sliding rear doors and easy shelf adjustment, ensuring streamlined workflow and efficient merchandising in high-traffic areas.
- Refrigeration: Self-contained Breeze-E Type II system ensures reliable temperature control
- Construction: Durable UV-coated frameless glass and powder-coated steel interior
- Accessibility: Rear sliding glass doors facilitate maintenance and restocking
- Flexibility: Removable, adjustable shelves for customized interior configurations
- Lighting: LED top and shelf lighting enhances product display visibility
Ideal for retail delis, convenience stores, or quick-service restaurants seeking dependable, energy-efficient refrigerated display solutions.
Structural Concepts NR7247RSV Technical Specs
The NR7247RSV model operates with a 1150 lbs weight and measures 71.75" wide by 33" deep with a height of 47.25". Its electrical requirements include a standard voltage of 120V, 60Hz frequency, and a typical amperage consistent with commercial refrigeration standards. The unit features an air-cooled, self-contained Breeze-E (Type II) refrigeration system with an ETL-Sanitation and cETLus certification for food safety and sanitation. It provides a consistent cooling capacity suitable for medium-volume foodservice operations, ensuring reliable temperature stability within a defined operating range. Its laminate exterior finish offers durability while maintaining a professional appearance. Dimensions support straightforward deployment in tight kitchen layouts, with a total weight of 1150 lbs, and a freight class of 150. The product includes sliding glass rear doors, adjustable shelves, and a coated coil for longevity and easy maintenance.
- Electrical Requirements: 120V, 60Hz, standard phase, suitable for typical restaurant circuits
- Cooling Method: Air-cooled self-contained Breeze-E Type II refrigeration
- Refrigeration Type: Self-contained system with coated coil for corrosion resistance
- Product Capacity: Designed to support medium throughput with reliable cold storage
- Construction & Finish: Laminate exterior with UV-coated glass and internal steel components
- Dimensions & Weight: 71-3/4" W x 33" D x 47-1/4" H, 1150 lbs
Electrical Compatibility: 120V power supply necessary for operation
Installation Clearance: Adequate airflow clearance for optimal cooling
Drainage & Maintenance: Easy access for cleaning and coil service
Refrigeration Setup: Factory-charged, with coil and condensate pan included
Operational Environment: Designed for ambient room temperatures up to 80°F for consistent performance
What is a commercial refrigerated display case?
A commercial refrigerated display case is a refrigeration unit designed for high-traffic foodservice or retail environments to showcase perishable products while maintaining optimal temperatures. It typically features glass front and sides for visibility, adjustable shelving, and self-contained refrigeration systems for easy installation. The Structural Concepts NR7247RSV reveal® model, installed as a freestanding unit, provides reliable, energy-efficient cooling with adjustable shelves and LED lighting, making it suitable for grocery, convenience, or quick-service restaurant applications. Its robust construction and user-friendly features support consistent product presentation and operational efficiency across various medium-volume foodservice settings.
Top Refrigerated Display Cases for Foodservice Operations
Top commercial refrigerated display cases ensure reliability, efficient performance, and optimal product presentation in busy foodservice environments. Structural Concepts NR7247RSV is a durable, restaurant-ready unit designed for medium-throughput retail and horeca settings with a focus on precise temperature control and ease of maintenance.
- Operation Type — suitable for medium-volume retail delis and convenience stores
- Kitchen Type — ideal for compact commercial foodservice spaces
- Foodservice Category — supports grocery, quick-service, and retail food merchandising
- Workload Qualifier — handles moderate throughput with consistent refrigeration
- Use Case — supports streamlined product display and efficient restocking workflows
Why Choose Structural Concepts NR7247RSV?
Why choose the Structural Concepts NR7247RSV reveal® refrigerated case over competing models? Its durable UV-coated glass, self-contained Breeze-E refrigeration, and efficient LED lighting provide reliable performance while enabling attractive product display. Its front and rear access facilitate maintenance without disrupting workflow, and its energy-efficient design reduces operational costs. Built with high-quality materials and intelligent layout, this model ensures long-term durability and optimal merchandising for busy foodservice environments.
- Compact footprint with a 71-3/4" width optimizes space utilization
- Self-contained Breeze-E (Type II) refrigeration ensures consistent cooling
- Durable UV-coated glass and laminate exterior withstand high-traffic wear
- LED lighting enhances product visibility with low energy consumption
- Sliding glass doors improve accessibility and ease of maintenance
