The Johnson Controls G770KHA2 Ignition Control is a commercial-grade intermittent pilot ignition module designed for reliable operation in HVAC and industrial heating systems. Manufactured by Johnson Controls, this model features a compact black box enclosure with precise circuitry to manage 24VAC power supply frequency at 50/60Hz. Its primary function is to control ignition sequences, including pre-purge and inter-purge timings, with no trial or retry functions, ensuring consistent ignition for natural gas and propane applications. Key specifications include a maximum current draw of 0.2 amps, a 1 Amp pilot valve control, and multiple connection points for sensor and grounding integration. The G770KHA2 ensures seamless compatibility with Garland ovens and other similar appliances, providing robust control for commercial heating systems through its durable construction and precise electrical profile.
Top Johnson Controls G770KHA2 Features
The G770KHA2 ignition control offers precise management of pilot ignition for commercial heating systems, featuring a compact black box design with user-friendly wiring connections. It includes a 15-second inter-purge timing and an 8-second pre-purge, tailored for industrial appliance integration, with high durability in demanding environments. Its straightforward installation and minimal maintenance make it suitable for HVAC technicians and industrial installers. The unit's configuration supports dependable ignition control, reducing downtime and troubleshooting in high-volume commercial settings.
- Robust 24VAC control circuitry for consistent ignition operations
- Durable black box enclosure withstands industrial environments
- Easy wiring connections with 1/4" tabs for sensor and ground linkage
- Compact dimensions (4.3" W x 5.5" D x 3.5" H) for space-efficient installation
- No trial or retry functions ensures straightforward operational logic
Ideal for commercial HVAC installations requiring reliable pilot ignition control.
Johnson Controls G770KHA2 Technical Specs
The Johnson Controls G770KHA2 ignition control operates on 24VAC at 50/60Hz within a compact form factor, measuring 4.3 inches wide, 5.5 inches deep, and 3.5 inches high, weighing only 1 pound for easy handling. Constructed from durable materials suited for industrial environments, it features an air-cooled design ensuring reliable performance during operation. With connections suitable for sensor inputs (MV and PV) and ground outlets, it integrates seamlessly into commercial systems, including Garland ovens and other gas-fired appliances. The controller's specifications include a maximum pilot valve current of 1 Amp, a control voltage supply of 24V, and a maximum current draw of 0.2 amps, supporting efficient operation without excessive power consumption. Its robust build and electrical parameters make it an optimal choice for medium-duty commercial applications requiring precise ignition timing and reliable control, with installation options compatible with various industrial setups.
- Electrical Requirements: 24VAC, 50/60Hz, 0.2A draw
- Dimensions: 4.3" W x 5.5" D x 3.5" H
- Construction & Finish: Durable black enclosure for industrial environments
- Connection Points: 9 terminals with 1/4" tabs for sensor, ground, and spark wiring
- Temperature Resistance: Suitable for operation in typical commercial heating environments
- Mounting & Compatibility: Bench-mounted support compatible with industrial gas appliances
What is a commercial ignition control?
A commercial ignition control is a device designed to manage and automate the ignition sequence in industrial and HVAC gas-fired systems. It ensures safe, reliable, and efficient pilot ignition by controlling timing sequences, sensors, and safety interlocks. The Johnson Controls G770KHA2 ignition control is commonly installed in commercial boilers, ovens, and heating equipment, such as Garland ovens, supporting medium-volume operation. It features precise control circuitry, timing functions, and durable construction, making it suitable for ensuring consistent ignition performance in demanding environments.
Top ignition control for commercial HVAC and industrial heating systems
The G770KHA2 ignition control from Johnson Controls offers robust, reliable operation in commercial heating applications, designed with a compact form to fit industrial environments. Manufactured by AllPoints, it provides precise pilot management for HVAC and gas-fired appliances, supporting operation types like medium-volume commercial kitchens and industrial facilities, ensuring consistent ignition in demanding foodservice and heating settings.
- HVAC and industrial gas systems — suitable for commercial kitchen equipment
- Compact footprint — ideal for space-constrained installations
- Reliable intermittent pilot control — supports consistent ignition sequences
- Durable construction — withstands harsh industrial environments
- Ease of wiring — designed for quick installation and maintenance
Why Choose Johnson Controls G770KHA2 Ignition Control?
The Johnson Controls G770KHA2 stands out due to its durable black box design, precise timing features, and seamless integration with industrial gas appliances. It offers a reliable ignition solution that minimizes system downtime and simplifies troubleshooting, surpassing many competitor models with its straightforward wiring and robust electrical specifications.
- Self-contained design for simplified installation
- Industrial-grade materials for longevity in demanding conditions
- Optimized control circuitry for consistent pilot ignition
- Compact form factor suitable for tight commercial spaces
- Seamless compatibility with Garland ovens and similar equipment
