The Garland 4515518 Open Burner Pilot Tube 19.5" X 5" Aluminium is a precision-engineered replacement component designed for commercial kitchen open burners, specifically within foodservice operations that demand durability and reliable performance. This pilot tube assembly features a robust aluminium construction for optimal heat resistance and longevity. Its technical design includes a 19.5-inch length with an integrated 5-inch width, capturing key specifications such as a 3/16" steel lower piece with a 12-1/4" center-to-center measurement, characterized by a 2-3/8" slot for precise installation. The unit incorporates dual pilot heads at both ends, facilitating consistent ignition processes. Its bent lower piece measures 16-7/16" before bending at a 90-degree angle with a 2-inch end, making it suitable for compatible Garland open burner models. This pilot tube is essential for ensuring stable flame ignition, reducing downtime, and maintaining efficient operation in high-demand commercial cooking environments.
Top AllPoints 4515518 Features
This pilot tube assembly offers precise alignment for reliable ignition in commercial open burner systems, constructed from durable aluminium to withstand high operational temperatures. Its complex shape with attached pieces simplifies installation and maintenance, improving workflow for restaurant kitchens and industrial food production. Designed for easy disassembly, the pilot heads on both ends ensure efficient flame control, minimizing failure rates in continuous operation scenarios.
- Robust aluminium construction for heat resistance and durability
- Precisely dimensioned 19.5" x 5" design for seamless burner integration
- Integrated dual pilot heads streamline ignition processes in busy kitchens
- Unique odd shape with attached pieces for simplified installation and servicing
- Steel lower component ensures structural integrity under thermal stress
Designed for replacing faulty pilot tubes in commercial open burners, this assembly is ideal for professional foodservice establishments requiring reliable ignition components.
AllPoints 4515518 Technical Specs
The AllPoints 4515518 is a self-contained pilot tube assembly crafted from high-quality aluminium, weighing approximately 0.16 lbs, with dimensions of 19.5 inches in length, 5 inches in width, and 0.88 inches in height. It features a steel lower piece measuring 16-7/16 inches, bent at a 90-degree angle at one end for compatibility with standard Garland open burner models. The assembly includes two pilot heads at each end, paired with a 3/16" tee unbent lower piece, enhancing ease of installation and maintenance. The component is manufactured in the United States and designed to operate within typical high-temperature ranges, resistant to deformation, and compatible with standard gas burner setups. Its placeholder for proprietary certifications indicates compliance with relevant safety standards, ensuring operational safety and reliability.
- Dimensions: 19.5" length, 5" width, 0.88" height
- Weight: 0.16 lbs including mounting components
- Material: Aluminium body with steel lower piece
- Manufactured in: United States
- Design features: Dual pilot heads, bent U-shaped lower piece
- Operating range: Suitable for high-temperature ignition systems
What is a commercial pilot tube assembly
A commercial pilot tube is a critical component within open burner ignition systems used in professional kitchens and industrial cooking environments. It functions as a conduit for gas ignition, delivering a consistent flame source to ensure reliable operation of gas burners. The Garland 4515518 Pilot Tube features precise dimensions, a durable aluminium construction, and dual pilot heads designed for seamless integration into Garland open burners. Installed in foodservice settings such as restaurants, catering facilities, and institutional kitchens, it is essential for maintaining safe and efficient flame operation, particularly in high-traffic and continuous-use scenarios.
Top open burner pilot tube for commercial foodservice environments
Constructed from high-durability aluminium, the Garland 4515518 pilot tube ensures reliable ignition in standard open burner systems for busy restaurant kitchens and industrial setups. Its precise dimensions and dual pilot heads facilitate smooth operation, making it compatible with mid-volume cooking workflows. This self-contained component provides a long-lasting solution for stable flame ignition, supporting efficient and safe food preparation in high-demand environments.
- Operation Type: Commercial open burner ignition
- Kitchen Setting: High-traffic restaurant kitchens
- Foodservice Category: Gas burner systems
- Workload Qualification: Moderate throughput operations
- Use Case: Reliable flame ignition in industrial cooking equipment
Why Choose AllPoints 4515518?
Compared to conventional pilot tubes, the AllPoints 4515518 offers enhanced durability with its aluminium construction and precision design for seamless burner compatibility. Its compact, complex shape reduces installation time and maintenance costs while ensuring consistent ignition performance. This model's sturdy steel lower piece and dual pilot heads optimize operational reliability and support the demands of high-volume commercial kitchens.
- Compact footprint simplifies installation in tight spaces
- Durable aluminium body withstands high-temperature conditions
- Dual pilot heads enhance ignition stability
- Precisely engineered dimensions for reliable compatibility
- Designed for maintenance ease reduces downtime in high-usage environments
