The AllPoints 264217 90 Degree Elbow Short Radius 3/4" is a high-precision brass fitting designed for professional commercial refrigeration and HVACR systems. Manufactured by AllPoints, this fitting features a 3/4" internal diameter female end and a short radius 90-degree bend, offering a compact and reliable connection for fluid transfer systems. Engineered to meet ASME standards, it ensures precise fit and enhanced durability, facilitating efficient system installation and maintenance in foodservice operations and commercial environments. Its robust copper construction presents excellent corrosion resistance, supporting long-term performance in demanding applications.
Top AllPoints 264217 Features
The AllPoints 264217 short radius elbow is designed for seamless integration in refrigeration and HVACR piping networks, providing precise 90-degree turns with minimal pressure loss. Its robust copper alloy construction ensures high durability under frequent thermal cycling, while its short radius design optimizes space in confined installations. The fitting’s female end simplifies quick, secure connections, reducing labor time and ensuring leak-free performance in commercial foodservice systems. Suitable for both new builds and maintenance of existing systems, it guarantees a reliable fluid pathway in demanding environments.
- Enhanced sealing performance — reducing leaks in refrigeration lines
- Durable copper alloy material resists corrosion and thermal stress
- Easy to install and disassemble — compatible with standard copper fittings
- Compact short radius design — ideal for space-constrained systems
- Manufactured to ASME standards for precision and reliability in HVACR applications
Designed for professional refrigeration installers and HVAC technicians seeking durable, space-efficient fittings for commercial systems.
AllPoints 264217 Technical Specs
The AllPoints 264217 short radius elbow features precise dimensional specifications: height of 1.25 inches, width of 0.75 inches, and depth of 2.5 inches. Constructed from high-quality copper, it weighs only 0.1 lbs, offering excellent corrosion resistance and long-term performance. The fitting is designed for use in commercial refrigeration and HVACR installations, accommodating standard 3/4" female connections. Manufactured in the United States, it complies with ASME standards, ensuring a consistent, high-quality fit in demanding environments. Its operating temperature range supports typical refrigeration and HVAC applications, with easy disassembly for maintenance or system modification.
- Material: Copper alloy for corrosion resistance
- Dimensions: Height 1.25", Width 0.75", Depth 2.5"
- Weight: 0.1 lbs (product only)
- Standards: Manufactured to ASME specifications
- Maximum operating temperature: Suitable for typical refrigeration and HVAC operation
- Electrical requirements: Not applicable for this fitting
- Plumbing compatibility: Fits 3/4" female copper pipe connections
- Installation clearance: Requires minimal space for tight routing
- Maintenance notes: Disassemble easily for system repairs
- Construction finish: Copper with standard finish suitable for cleaning and system cleaning routines
What is a commercial 90 degree elbow?
A commercial 90 degree elbow is a pipe fitting used to change the direction of flow within a piping system at a right angle. Typically made of copper or brass, this component is installed in refrigeration, HVAC, and fluid transfer systems to facilitate space-efficient piping layouts. The AllPoints 264217 90 Degree Elbow Short Radius 3/4" is designed for precision in professional environments, offering a secure, leak-free connection with a short radius bend ideal for tight spaces. Used in installation and maintenance of commercial refrigeration and air conditioning setups, it ensures accurate directional flow control and system integrity in foodservice and HVAC applications.
Top commercial copper pipe fittings for refrigeration in foodservice settings
The AllPoints 264217 90 Degree Elbow Short Radius 3/4" provides durable, high-precision connections for commercial refrigeration systems, supporting efficient system flow and space optimization. Built with rugged copper alloy material, it suits moderate workloads in foodservice environments requiring reliable fluid handling and system longevity.
- Commercial refrigeration setup — supports space-efficient piping layouts
- Medium workload — ideal for typical foodservice throughput
- Commercial kitchen equipment — enhances system reliability and ease of maintenance
- System installation — compatible with standard copper piping and fittings
- Space-constrained environments — short radius design facilitates tight routing
Why Choose AllPoints 264217?
Why Choose the AllPoints 264217 90 Degree Elbow Short Radius 3/4" over other fittings? Its manufacturing quality ensures precise and consistent fittings that resist corrosion and thermal stress, supporting long-term system reliability. The short radius design maximizes space efficiency, while its ASME compliance guarantees professional standards for commercial refrigeration and HVACR applications. Enhanced connection security reduces system leaks, improving operational efficiency and maintenance ease compared to standard fittings.
- Compact footprint — ideal for restricted space installations
- Superior corrosion resistance — extends lifespan in cold and humid environments
- Made in the United States — assured quality control and standards
- Leak-free performance — reduces system downtime and clean-up costs
- Designed for professional HVACR and refrigeration systems — ensures system integrity
