The Piper Products 13-503142 Relay is a high-performance relay component designed for industrial automation and control systems. Manufactured by Piper Products, this OEM relay features a robust construction with precise electrical specifications, making it suitable for applications requiring reliable switching operations. Its compact form factor measures 3.3 inches in width, 5.9 inches in depth, and 2.45 inches in height, with a weight of only 0.23 lbs, facilitating easy integration into various control panels. The relay provides consistent operation under demanding conditions, ensuring efficient workflow continuity in commercial and industrial environments.
Top Piper Products 13-503142 Relay Features
The Piper Products 13-503142 Relay offers enhanced relay switching capabilities tailored for medium workload industrial controls. Its durable coil and contact materials ensure long-term operational integrity, while its compact design simplifies installation in crowded control panels. Suitable for automation in manufacturing, the relay supports fast response times and reliable circuit toggling. It is engineered for straightforward maintenance, promoting minimal downtime through accessible terminals and clear wiring configurations. Ideal for use in process automation, this relay optimizes system workflows, ensuring precise switching with minimal contact fatigue.
- Functionality: Precise switching for automation control applications
- Durability traits: Built with high-grade electrical contact materials
- Ease-of-use: Screw terminal connections for quick installation
- Workplace fit: Compact footprint suits dense control panel layouts
- Workflow benefit: Enhances system reliability with rapid toggling capabilities
Ideal for integration into control systems requiring dependable relay operation in industrial environments.
13-503142 Technical Specs
The Piper Products 13-503142 Relay operates with a voltage requirement of 24V AC/DC and supports up to 10A current switching capacity, making it suitable for standard industrial control circuits. Its coil is designed for consistent performance across a temperature range of -20°F to 140°F (-29°C to 60°C), ensuring operational reliability in varying environments. Constructed with durable plastic and metal components, the relay features a compact design with dimensions of 3.3 inches width, 5.9 inches depth, and 2.45 inches height. The relay’s contact configuration supports single-pole, double-throw switching, optimized for control circuit applications requiring fast response times and dependable operation. Maintenance involves simple inspection of terminals and contact points, with no special cleaning requirements beyond routine checks. It is compatible with standard DIN mounting rails and includes screw terminals for secure wiring connection. Its self-contained design requires no additional cooling or external power sources beyond specified electrical inputs.
- Electrical requirements: 24V AC/DC, 10A maximum switching load
- Construction & finish: High-grade plastic housing with metal contacts
- Dimensions: 3.3" W x 5.9" D x 2.45" H
- Temperature resistance: -20°F to 140°F (-29°C to 60°C) operational range
- Mounting compatibility: Supports DIN rail mounting and screw terminal connections
- Electrical compatibility: Requires 24V AC/DC power supply
- Wiring considerations: Secure screw terminals for simplified installation
- Operational environment: Suitable for control panels with moderate ambient temperatures
- Maintenance needs: Routine terminal inspection recommended for longevity
- Installation space: Fits standard panel cutouts due to its compact size
