The Newco 111684 Triac 40amp 600v is a high-performance semiconductor device used in industrial control and switching applications, designed under the AllPoints brand. This triac enables precise control of AC power flow in various electrical systems with a maximum voltage rating of 600V and a current capacity of 40A. Its robust construction and reliable operation make it suitable for complex, high-demand environments such as industrial automation and power management systems. The device features a compact design with precise electrical specifications, ensuring consistent performance and integration within power control modules alongside other industrial components.
Top AllPoints 111684 Features
The Newco 111684 Triac offers marked advantages for commercial electrical applications, including reliable high-current switching, durable silicon construction, and ease of installation in control circuits. Its robust design withstands frequent switching cycles, making it ideal for automation in manufacturing lines, motor control, and lighting dimming systems. Suitable for mounting on PCB or panel applications, it facilitates quick maintenance and seamless circuit integration for medium to high workload environments, enhancing operational efficiency in industrial facilities.
- Current Capacity: Handles 40A for reliable high-load switching
- Material Grade: Silicon-based, high-durability internal structure
- Ease of Maintenance: Compact size simplifies integration and replacement
- Use Case Fit: Designed for power control modules in industrial automation
- Workflow Benefit: Supports efficient circuit management and switching reliability
Ideal for control panels requiring robust power switching components
AllPoints 111684 Technical Specs
The Newco 111684 Triac operates at a maximum voltage of 600V, ensuring its suitability for controlling substantial AC loads in medium-voltage environments. It is rated for continuous operation at 40A, with a compact profile measuring approximately 0.95 inches in height, 0.95 inches in width, and 1.25 inches in depth. Constructed from high-grade silicon, it provides excellent thermal stability and durability in industrial settings. The device is designed for panel mounting and features a lightweight of just 0.03 lbs, facilitating straightforward installation in control boxes or automated equipment. Its self-commutating properties ensure dependable switching performance, and it is compatible with various control electronics that require precise AC power modulation. No special cooling methods are necessary, supporting efficient energy use in power control applications.
- Electrical Requirements: 600V voltage, 40A current
- Cooling Method: Air-cooled, no additional cooling required
- Construction & Finish: Silicon semiconductor, durable package
- Dimensions: 0.95" W x 1.25" D x 0.95" H
- Weight: 0.03 lbs
- Temperature Resistance: Designed for standard industrial operating ranges
- Electrical Compatibility: Suitable for 600V AC systems with control circuitry
- Mounting Requirements: Panel mounting with compatible screw terminals
- Power Supply Needs: Compatible with typical control relays and drivers in automation setups
- Ventilation: No dedicated cooling system, relies on ambient airflow
- Wiring: Minimized wiring complexity with straightforward terminal connections
What is a commercial triac?
A commercial triac is a solid-state component designed for AC power switching in control systems across industrial and automation environments. The Newco 111684 Triac, with its 40amp 600V ratings, is used for managing high-current loads in control panels, motor drives, and lighting circuits. Installed in power control modules, it enables efficient, reliable switching of AC loads with precise modulation capabilities, making it suitable for various medium-volume applications such as manufacturing automation or industrial process control.
Top triacs for industrial automation in manufacturing facilities
Industrial automation relies on high-quality triacs like the Newco 111684 to ensure robust power switching and reliable electrical performance. Built with durable silicon components, these devices support operation in control panels within manufacturing environments, ideal for medium workload management. They facilitate precise power regulation and system efficiency in industrial processes, making them a critical element in modern control architectures.
- Operation Type — suitable for power switching in control panels
- Workload Qualifier — designed for moderate throughput control
- Application Setting — ideal for manufacturing automation systems
- Control Environment — suited for industrial automation workflows
- Use Case — medium-duty control in production equipment
Why Choose AllPoints 111684?
Designed with a robust silicon construction and high current capacity, the AllPoints 111684 triac ensures reliable switching performance in power control systems. Its compact footprint and straightforward installation streamline integration into existing industrial control architectures, supporting efficient operation. Compared to typical models, it offers enhanced durability for medium workload applications and seamless circuit compatibility, elevating operational reliability in commercial electrical systems.
- Compact, space-efficient design for control panels
- High-performance switch for 40A and 600V loads
- Material withstands repeated switching cycles
- Simple installation reduces maintenance time
- Optimized for moderate to industrial automation environments
