Delfield 8186-EFP_115/60/1 LiquiTec Six Pan Drop-In Cooled Cold Food Well

Specification Specifications
Ship Weight 306 LBS
Manufacturer Delfield
Model Number 8186-EFP_115/60/1
Manufacturer Part # 8186-EFP_115/60/1
Oversized Shipping No
Hazardous Material No
NSF Listed Yes
cUL Listed Yes
UL Listed Yes
Voltage 115
Hertz 60
Phase 1
Amperage 4.8
Horsepower 1/3
Pan Capacity (6) 12" x 20" Pans
Color Silver
Base Material Stainless Steel
Dimensions (WxDxH) 86" x 26" x 24.24"
View all Specifications

The Delfield 8186-EFP Six Pan Drop In LiquiTec Cooled Cold Food Well keeps foods chilled at the ideal temperature thanks to electronic temperature control and expansive valve standard. Built with LiquiTec Cold Pans with Eutectic Fluid technology, food in pans are allowed to be flush with counter tops for an elegant, functional display. Eutectic fluid remains liquid regardless of temperature and in turn, provides consistent and even cooling. The Delfield 8186-EFP accommodates (6) 12" x 20" pans constructed of stainless steel for easy cleaning and features environmentally friendly being Non GWP (Global Warming Potential) and Non ODP (Ozone Depletion Potential) polyurethane foam insulation.

Delfield 8186-EFP_115/60/1 Features

  • Drop-In Cool Food Well
  • Material: Stainless Steel
  • Color: Silver
  • Electrical Specifications: 115V/60Hz/1-ph
  • Amperage: 4.8
  • Horsepower: 1/3
  • R290 Refrigerant
  • Fits (6) 12" x 20" Pans
  • One-Piece Stainless Steel Top
  • LiquiTec Cold Pans With Eutectic Fluid Technology
  • 1/2" Stainless Steel Drains With Manifold
  • Polyurethane Foam Insulation
  • Non-Marring Press Fit Top Gasket
  • Stainless Steel Louver
  • Electronic Temperature Control
  • Expansion Valve
  • 8' Cord And Plug
  • 85" x 25" Cutout Required
  • NEMA 5-15P
  • UL Listed
  • cUL Listed
  • NSF Listed

Delfield 8186-EFP_115/60/1 Benefits

  • Sturdy stainless steel construction helps ensure longevity
  • Polyurethane insulation helps maintain ideal temperatures
  • Electronic temperature control provides precise usage

Overall Dimensions:

Width: 86"

Depth: 26"

Height: 24-1/4"

View all Description
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
NSF Listed
NSF Listed
This item meets the standards imposed by NSF International, which focuses on public safety, health, and the environment.
UL Listed
UL Listed
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).
This unit comes with a NEMA 5-15P plug.
Not For Residential Use
Not For Residential Use
Installed in a non-commercial setting will void your homeowner's insurance and the equipment manufacturer's warranty.
Free Shipping
Add this item to the cart to calculate your shipping rate
Contact Us for Details
Lead time varies; contact our team with your ZIP code for more info.
  • Drop-In Cool Food Well
  • 115 Volts / 60 Hertz / 1-phase
  • 4.8 Amps / 1/3 Horsepower
  • R290 Refrigerant
  • Fits (6) 12" x 20" Pans
  • One-Piece Stainless Steel Top
  • 1/2" Stainless Steel Drains With Manifold
  • Polyurethane Foam Insulation
  • 8' Cord And Plug
  • 85" x 25" Cutout Required
  • Warranty Info
    One Year Parts and 90 Day Labor Standard Warranty
