Vulcan V6B36 Natural Gas V Series 36" Wide Modular Frame 6 Cast Iron Open Burner Stainless Steel Range Without Legs, 210,000 BTU
| Ship Weight | 400 lb |
| Manufacturer | Vulcan |
| Model Number | V6B36 |
| Manufacturer Part # | V6B36 |
| Hazardous Material | No |
| Oversized Shipping | No |
| Type | Commercial Gas Range |
| Height | 13 3/4 Inches |
| Width | 36 Inches |
| Depth | 36 3/4 Inches |
| Base Material | Stainless Steel |
| Color | Silver |
| Base Type | Modular Frame |
| Burner Type | Open Burner |
| Number Of Burners | 6 |
| Burner BTU | 35,000 |
| Burner Material | Cast Iron |
| CSA Design Certified | Yes |
| CSA Blue Flame Certified | Yes |
| NSF Listed | Yes |
| Riser Height | 4 Inches |
| Power | Gas / Electric |
| Total BTU | 210,000 |
| Gas Connection | 1 1/4" Diameter Rear Gas Connection |
| Gas Type | Natural Gas |
| Regulator Included | No |
| Voltage | 115 |
| Phase | 1 |
| Amps | 4 |
| Power Cord Length | 9 ft |
| Plug | NEMA 5-15P |
| Legs | None |
| Brand Line | V Series |
The V6B36 is the heavy-duty V Series 36" wide gas-powered open burner range from Vulcan that has a modular frame, and 6 cast iron open burners with individual pilots and controls. This modular range does not include legs.
There is durable stainless steel construction on the front, front top ledge, sides, base, burner box, and 4" high stub riser of this open burner range that makes it durable enough to stand up to the daily usage of any commercial kitchen environment.
This commercial gas open burner range is CSA Blue Flame certified, CSA Design certified, and it is NSF listed for safety.
This V6B36 commercial gas open burner range operates on Natural Gas at 35,000 BTU per burner, for a total of 210,000 BTU. All gas connections should be made by qualified personnel who will follow all of the proper safety codes and guidelines.
This gas open burner range has a 1 1/4" diameter front gas manifold and a 1 1/4" rear gas connection. All gas connections should be made by qualified personnel who will follow all of the proper safety codes and guidelines.
V series units are all modular and interchangeable to allow you to create the perfect customized workstation, including a variety of types of ranges from open burners, hot tops, French tops, charbroilers, and griddles, to other units like refrigerated bases, cabinets, convection or finishing ovens.
Vulcan V6B36 Features
- V Series heavy-duty 36" wide range
- Base Type: Modular Frame
- Power Type: Gas / Electric
- Base Material: Stainless Steel
- Burner Type: Open burner
- Burner Material: Cast iron
- Number of Burners: 6
- Burner BTU: 35,000
- Individual burner pilots and controls
- Gas Type: Natural Gas
- Total BTU: 210,000
- 4" stainless steel stub riser
- Gas Connection: 1 1/4" diameter rear gas connection
- Legs: None
- CSA Blue Flame certified
- CSA Design certified
- NSF listed for safety
Vulcan V6B36 Benefits
- Modular and interchangeable V series units allow you to create the perfect customized workstation
- Energy-efficient heavy-duty burners
- Durable stainless steel and heavy-duty cast iron grates stand up to any commercial kitchen environment
Overall Dimensions:
Height: 13 3/4"
Width: 36"
Depth: 36 3/4"
