Vulcan V2P36 Natural Gas V Series 36" Wide Modular Frame Dual 1/2" Thick Steel Plancha Heavy-Duty Stainless Steel Range Without Legs, 35,000 BTU
|Ship Weight||404 lb|
|Manufacturer Part #||V2P36|
|Type||Commercial Gas Range|
|Height||13 3/4 Inches|
|Depth||36 3/4 Inches|
|Base Material||Stainless Steel|
|Base Type||Modular Frame|
|Number Of Burners||2|
|Burner Type||Plancha Top|
|CSA Design Certified||Yes|
|CSA Blue Flame Certified||Yes|
|Riser Height||4 Inches|
|Gas Connection||1 1/4" Diameter Rear Gas Connection|
|Gas Type||Natural Gas|
|Brand Line||V Series|
The V2P36 is the heavy-duty V Series 36" wide gas-powered Plancha top range from Vulcan that has a modular frame, and two 1/2" thick 18" wide steel plancha tops with individual pilots and controls, and a 3-sided grease trough. This Plancha top range does not come included with legs.
There is durable stainless steel construction on the front, front top ledge, sides, base, burner box, and 4" high stub riser of this Plancha top range that makes it durable enough to stand up to the daily usage of any commercial kitchen environment.
This commercial gas Plancha top burner range is CSA Blue Flame certified, CSA Design certified, and it is NSF listed for safety.
This V2P36 commercial gas Plancha top burner range operates on Natural Gas at 17,500 BTU for each Plancha top for a total 35,000 BTU for the unit. All gas connections should be made by qualified personnel who will follow all of the proper safety codes and guidelines.
This gas Plancha top burner range has a 1 1/4" diameter front gas manifold and a 1 1/4" rear gas connection. All gas connections should be made by qualified personnel who will follow all of the proper safety codes and guidelines.
V series units are all modular and interchangeable to allow you to create the perfect customized workstation, including a variety of types of ranges from open burners, hot tops, French tops, charbroilers, and griddles, to other units like refrigerated bases, cabinets, convection or finishing ovens.
Vulcan V2P36 Features
- V Series heavy-duty 36" wide range
- Base Type: Modular Frame
- Power Type: Gas
- Base Material: Stainless Steel
- Burner Type: Plancha Top burner
- Burner Material: Steel
- Plancha Burner Width: 18"
- Number of Plancha Burners: 2
- 3-sided grease trough
- Burner BTU: 17,500
- Individual burner pilots and controls
- Gas Type: Natural Gas
- Total BTU: 35,000
- 4" stainless steel stub riser
- Gas Connection: 1 1/4" diameter rear gas connection
- Legs: None
- CSA Blue Flame certified
- CSA Design certified
- NSF listed for safety
Vulcan V2P36 Benefits
- Modular and interchangeable V series units allow you to create the perfect customized workstation
- Energy-efficient heavy-duty burners
- Durable stainless steel and heavy-duty cast iron grates stand up to any commercial kitchen environment
Height: 13 3/4"
Depth: 36 3/4"
