Vulcan V2BG8T Natural Gas V Series 36" Wide Thermostatic-Control Modular Frame 18" Manual Griddle 2 Cast Iron Open Burner Stainless Steel Range On 6" Legs, 100,000 BTU
|Ship Weight||432 lb|
|Manufacturer Part #||V2BG8T|
|Type||Commercial Gas Range|
|Height||13 3/4 Inches|
|Depth||36 3/4 Inches|
|Base Material||Stainless Steel|
|Base Type||Modular Frame|
|Burner Type||Open Burner|
|Number Of Burners||2|
|Burner Material||Cast Iron|
|Number Of Griddle Plates||1|
|Griddle Plate Width||18 Inches|
|Griddle Plate BTU||30,000|
|Griddle Plate Thickness||3/4 Inches|
|CSA Design Certified||Yes|
|CSA Blue Flame Certified||Yes|
|Riser Height||4 Inches|
|Gas Connection||1 1/4" Diameter Rear Gas Connection|
|Gas Type||Natural Gas|
|Legs||4" Adjustable Flanged Feet|
|Brand Line||V Series|
V series units are all modular and interchangeable to allow you to create the perfect customized workstation, including a variety of types of ranges from open burners, hot tops, French tops, charbroilers, and griddles, to other units like refrigerated bases, cabinets, convection or finishing ovens.
The V2BG8T is the heavy-duty V Series 36" wide gas-powered open burner / griddle range from Vulcan that has a modular frame, thermostatic controls, and a 3/4" thick ground steel 18" wide griddle plate, and 2 cast iron open burners with individual pilots and controls. This range stands firmly on 4" adjustable flanged feet.
This commercial gas open burner / griddle range is CSA Blue Flame certified, CSA Design certified, and it is NSF listed for safety.
There is a 4" stainless steel stub riser on this unit and the durable stainless steel construction of the front, front top ledge, sides, base, burner box, and stub back on this open burner range that makes it durable enough to stand up to the daily usage of any commercial kitchen environment.
This V2BG8T commercial gas open burner / griddle range operates on Natural Gas at 35,000 BTU per burner, and 30,000 BTU for the griddle, for a total of 100,000 BTU and it has a 1 1/4" diameter front gas manifold and a 1 1/4" rear gas connection. All gas connections should be made by qualified personnel who will follow all of the proper safety codes and guidelines.
Vulcan V2BG8T Features
- V Series heavy-duty 36" wide range
- Base Type: Modular Frame
- Control Type: Thermostatic
- Base Material: Stainless Steel
- Burner Type: Open burner / Griddle
- Burner Material: Cast iron
- Number of Burners: 2
- Burner BTU: 35,000
- Individual burner pilots and controls
- Number of Griddle Plates: 1
- Griddle Plate BTU: 30,000
- Griddle Plate Width: 18"
- Gas Type: Natural Gas
- Total BTU: 100,000
- 4" stainless steel stub riser
- Gas Connection: 1 1/4" diameter rear gas connection
- Legs: 4" adjustable flanged feet
- CSA Blue Flame certified
- CSA Design certified
- NSF listed for safety
Vulcan V2BG8T Benefits
- Energy-efficient heavy-duty burner
- Modular and interchangeable V series units allow you to create the perfect customized workstation
- Durable stainless steel and heavy-duty cast iron grates stand up to any commercial kitchen environment
Height: 13 3/4"
Depth: 36 3/4"
