Vulcan V2BG24 Natural Gas V Series 36" Wide Modular Frame Manual-Control 24" Wide Griddle 2 Cast Iron Open Burner Heavy-Duty Stainless Steel Range Without Legs, 130,000 BTU

Item
#173460
MFG
#V2BG24_NAT
Convection Oven Base On Casters Shown
Specification Specifications
Ship Weight 367 lb
Manufacturer Vulcan
Model Number V2BG24
Manufacturer Part # V2BG24
Hazardous Material No
Oversized Shipping No
Type Commercial Gas Range
Height 13 3/4 Inches
Width 36 Inches
Depth 41 7/8 Inches
Base Material Stainless Steel
Color Silver
Base Type Modular Frame
Control Type Manual
Number Of Burners 2
Burner BTU 35,000
Burner Type Open Burner
Burner Material Cast Iron
Number Of Griddle Plates 1
Griddle Plate Width 24 Inches
Griddle Plate BTU 60,000
Griddle Plate Thickness 3/4 Inches
CSA Design Certified Yes
CSA Blue Flame Certified Yes
NSF Listed Yes
Riser Height 4 Inches
Power Gas
Total BTU 130,000
Gas Connection 1 1/4" Diameter Rear Gas Connection
Gas Type Natural Gas
Regulator Included No
Legs None
Brand Line V Series
View all Specifications
Description

V series units are all modular and interchangeable to allow you to create the perfect customized workstation, including a variety of types of ranges from open burners, hot tops, French tops, charbroilers, and griddles, to other units like refrigerated bases, cabinets, convection or finishing ovens.

This commercial gas Open burner / Griddle range is CSA Blue Flame certified, CSA Design certified, and it is NSF listed for safety.

The V2BG24 is the heavy-duty V Series 36" wide gas-powered open burner / Griddle range from Vulcan that has a modular frame, manual controls, and a 3/4" thick ground steel 24" wide griddle plate, and 2 cast iron open burners with individual pilots and controls. This modular range comes without legs.

There is a 4" stainless steel stub riser on this unit and the stainless steel front, front top ledge, sides, base, burner box, and stub back on this Open burner / Griddle range that makes it durable enough to stand up to the daily usage of any commercial kitchen environment.

This V2BG24 commercial gas Open burner / Griddle range operates on Natural Gas at 35,000 BTU per burner, and 60,000 BTU for the griddle, for a total of 130,000 BTU and it has a 1 1/4" diameter front gas manifold and a 1 1/4" rear gas connection. All gas connections should be made by qualified personnel who will follow all of the proper safety codes and guidelines.

Vulcan V2BG24 Features

  • V Series heavy-duty 36" wide range
  • Base Type: Modular Frame
  • Base Material: Stainless Steel
  • Burner Type: Open burner / Griddle
  • Control Type: Manual
  • Burner Material: Cast iron
  • Number of Burners: 2
  • Burner BTU: 35,000
  • Individual burner pilots and controls
  • Number of Griddle Plates: 1
  • Griddle Plate Width: 24"
  • Griddle Plate BTU: 60,000
  • Gas Type: Natural Gas
  • Total BTU: 130,000
  • 4" stainless steel stub riser
  • Gas Connection: 1 1/4" diameter rear gas connection
  • Legs: None
  • CSA Blue Flame certified
  • CSA Design certified
  • NSF listed for safety

Vulcan V2BG24 Benefits

  • Energy-efficient heavy-duty burner
  • Modular and interchangeable V series units allow you to create the perfect customized workstation
  • Durable stainless steel and heavy-duty cast iron grates stand up to any commercial kitchen environment

Overall Dimensions:
Height: 13 3/4"
Width: 36"
Depth: 41 7/8"

View all Description
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
NSF Listed
NSF Listed
This item meets the standards imposed by NSF International, which focuses on public safety, health, and the environment.
1 1/4" Gas Connection
1 1/4" Gas Connection
This unit comes with a 1 1/4" gas connection.
CSA Blue Flame
CSA Blue Flame
This item has been certified by the Canadian Standards Association (CSA) and meets applicable Canadian standards for appliances using gas or petroleum fuel.
CSA Design Cert
CSA Design Cert
This item has been certified by the Canadian Standards Association (CSA) and meets applicable U.S. standards.
Not For Residential Use
Not For Residential Use
Installed in a non-commercial setting will void your homeowner's insurance and the equipment manufacturer's warranty.
Free Shipping
Add this item to the cart to calculate your shipping rate
$8,819.00
Each
Shipping
Lead time varies; contact our team with your ZIP code for more info.
  • Individual burner pilots and controls
  • Gas Type: Natural Gas
  • Total BTU: 130,000
  • V Series heavy-duty 36" wide range
  • 4" stainless steel stub riser
  • 1 1/4" gas connection
  • Base Type: Modular Frame
  • Base Material: Stainless Steel
  • Burner Type: Open burner
  • Legs: None
  • CSA Design & CSA Blue Flame certified
  • NSF listed for safety
  • Burner Material: Cast iron
  • Number of Burners: 2
  • Burner BTU: 35,000
  • Number of Griddle Plates: 1
  • Griddle Plate Width: 24"
  • Griddle Plate BTU: 60,000
  • Warranty Info
    1 Year Parts and Labor Warranty
