Vulcan V2BG18 Natural Gas V Series 36" Wide Modular Frame Manual-Control 18" Wide Griddle 2 Cast Iron Open Burner Heavy-Duty Stainless Steel Range Without Legs, 100,000 BTU
| Ship Weight | 332 lb |
| Manufacturer | Vulcan |
| Model Number | V2BG18 |
| Manufacturer Part # | V2BG18 |
| Hazardous Material | No |
| Oversized Shipping | No |
| Type | Commercial Gas Range |
| Height | 13 3/4 Inches |
| Width | 36 Inches |
| Depth | 41 7/8 Inches |
| Base Material | Stainless Steel |
| Color | Silver |
| Base Type | Modular Frame |
| Control Type | Manual |
| Number Of Burners | 2 |
| Burner BTU | 35,000 |
| Burner Type | Open Burner |
| Burner Material | Cast Iron |
| Number Of Griddle Plates | 1 |
| Griddle Plate Width | 18 Inches |
| Griddle Plate BTU | 35,000 |
| Griddle Plate Thickness | 3/4 Inches |
| CSA Design Certified | Yes |
| CSA Blue Flame Certified | Yes |
| NSF Listed | Yes |
| Riser Height | 4 Inches |
| Power | Gas |
| Total BTU | 100,000 |
| Gas Connection | 1 1/4" Diameter Rear Gas Connection |
| Gas Type | Natural Gas |
| Regulator Included | No |
| Legs | None |
| Brand Line | V Series |
V series units are all modular and interchangeable to allow you to create the perfect customized workstation, including a variety of types of ranges from open burners, hot tops, French tops, charbroilers, and griddles, to other units like refrigerated bases, cabinets, convection or finishing ovens.
This commercial gas Open burner / Griddle range is CSA Blue Flame certified, CSA Design certified, and it is NSF listed for safety.
The V2BG18 is the heavy-duty V Series 36" wide gas-powered Open burner / Griddle range from Vulcan that has a modular frame, manual controls, and a 3⁄4" thick ground steel 18" wide griddle plate, and 2 cast iron open burners with individual pilots and controls. This modular range comes without legs.
There is a 4" stainless steel stub riser on this unit and the stainless steel front, front top ledge, sides, base, burner box, and stub back on this Open burner / Griddle range that makes it durable enough to stand up to the daily usage of any commercial kitchen environment.
This V2BG18 commercial gas Open burner / Griddle range operates on Natural Gas at 35,000 BTU per burner, and 30,000 BTU for the griddle, for a total 100,000 BTU and it has a 1 1/4" diameter front gas manifold and a 1 1/4" rear gas connection. All gas connections should be made by qualified personnel who will follow all of the proper safety codes and guidelines.
Vulcan V2BG18 Features
- V Series heavy-duty 36" wide range
- Base Type: Modular Frame
- Base Material: Stainless Steel
- Control Type: Manual
- Burner Type: Open burner / Griddle
- Burner Material: Cast iron
- Number of Burners: 2
- Burner BTU: 35,000
- Individual burner pilots and controls
- Number of Griddle Plates: 1
- Griddle Plate Width: 18"
- Griddle Plate BTU: 30,000
- Gas Type: Natural Gas
- Total BTU: 100,000
- 4" stainless steel stub riser
- Gas Connection: 1 1/4" diameter rear gas connection
- Legs: None
- CSA Blue Flame certified
- CSA Design certified
- NSF listed for safety
Vulcan V2BG18 Benefits
- Energy-efficient heavy-duty burner
- Modular and interchangeable V series units allow you to create the perfect customized workstation
- Durable stainless steel and heavy-duty cast iron grates stand up to any commercial kitchen environment
Overall Dimensions:
Height: 13 3/4"
Width: 36"
Depth: 41 7/8"
