The Cornelius 631100043 CB1522 Post-Mix Soda Beverage Dispenser Drop-in Ice Cooled is a commercial-grade in-counter soda and beverage dispensing unit designed for high-volume foodservice environments. Built by Cornelius, it features a durable stainless steel exterior and a head with five lever valves for precise beverage control. Its self-contained refrigeration system, utilizing ice cooling, provides a 60 lbs. ice capacity to maintain optimal serving temperatures. The unit's compact dimensions—15" width, 23" depth, and 33" height—allow straightforward installation in commercial kitchens, bars, or convenience store counters, with a 4-1 carb/non-carb manifold to facilitate versatile beverage mixing. Its built-in drip tray simplifies cleaning, ensuring sanitation standards are maintained for busy operations. Equipped for 115V electrical supply, it delivers reliable performance suitable for continuous service, making it an essential component for beverage stations handling large customer throughput.
Top Cornelius 631100043 CB1522 Features
The Cornelius CB1522 soda and beverage dispenser offers high-capacity ice-cooled operation, featuring five lever valves for individual drink control. Its all-stainless steel construction ensures durability and ease of cleaning, ideal for moderate- to high-volume venues. The unit’s drop-in design simplifies installation in existing counters, while the built-in drip tray facilitates sanitation. The integrated glass clearance of 9-3/4" accommodates standard cups, optimizing workflow. Its 60 lbs. ice capacity supports consistent cooling during peak service hours. The 4-1 carb/non-carb manifold provides versatile beverage configuration, enhancing operational flexibility.
- Capacity: 60 lbs. ice storage supports extended service periods
- Material: All stainless steel exterior for durability and easy cleaning
- Ease of Maintenance: Built-in drip tray simplifies sanitation routine
- Installation Fit: Drop-in design with 15-1/4" x 23-1/4" cutout required
- Performance: 115V, 1.5A operation ensures reliable, continuous beverage service
Ideal for foodservice venues requiring efficient, high-volume soda dispensing with easy maintenance and reliable performance.
Cornelius 631100043 CB1522 Technical Specs
The Cornelius CB1522 beverage dispenser operates on standard 115V power at 60 Hz with a 1.5-amp draw, making it suitable for typical commercial electrical systems. It features self-contained refrigeration with ice cooling to maintain beverages at optimal temperatures; however, it does not specify water-cooled or remote systems. The unit’s refrigeration capacity allows for the storage of up to 60 lbs. of ice, ensuring consistent cooling during high-demand periods. Its all stainless steel exterior provides structural resilience and surface durability, suitable for frequent cleaning. Dimensions of 15" wide, 23" deep, and 33" high with a weight of 148 lbs. make it compatible with standard countertop cutouts—15-1/4" x 23-1/4". The dispenser includes five lever valves for precise beverage flow control, with a built-in drip tray for sanitation and maintenance ease. The unit is NSF and UL listed, ensuring compliance with industry safety standards. It supports a wide operating temperature range suitable for commercial beverage applications, and its robust construction ensures longevity in busy foodservice environments.
- Electrical Requirements: 115V, 60Hz, 1.5A
- Cooling Method: Self-contained ice-cooled refrigeration
- Refrigeration Type: Self-contained
- Production Capacity: Supports high-volume beverage service with 60 lbs. ice capacity
- Construction & Finish: All stainless steel exterior for durability and sanitation
- Dimensions: 15" W x 23" D x 33" H; cutout needed 15-1/4" x 23-1/4"
- Weight: 148 lbs. (product weight)
- Temperature Range: Suitable for beverage cooling within standard operating temps
- Electrical Compatibility: Must connect to 115V outlets
- Installation Clearance: Requires 15-1/4" x 23-1/4" cutout for countertop mounting
- Drainage Setup: Built-in drip tray for sanitation and overflow management
- Airflow & Ventilation: Adequate clearance around unit recommended for cooling efficiency
- Cleaning Routine: Disassemble drip tray and lever valves for sanitation
What is a commercial soda ice & beverage dispenser?
A commercial soda ice & beverage dispenser is a heavy-duty, in-counter unit designed to deliver pre-mixed or post-mixed sodas and beverages rapidly and consistently in high-volume foodservice settings. Constructed with durable stainless steel and equipped with self-contained refrigeration, it maintains optimal temperatures using ice cooling, supporting continuous operation. The Cornelius 631100043 CB1522 model, installed in undercounter setups, is ideal for restaurants, convenience stores, and catering facilities that require reliable, easy-to-maintain beverage distribution systems capable of handling frequent customer demand with minimal downtime.
Top In-Counter Soda Dispensers for Foodservice Environments
Designed for moderate throughput operations, the Cornelius CB1522 is a top commercial in-counter soda and beverage dispenser. It features a robust build with a compact footprint, perfect for busy cafes and quick-service establishments. Its ice-cooled refrigeration system ensures consistent beverage temperature, supporting efficient workflow in foodservice kitchens with reliable performance by Cornelius 631100043.
- Operation Type — ideal for fast-paced beverage stations
- Kitchen Setting — suitable for compact commercial spaces
- Foodservice Category — fits convenience stores and cafes
- Workload Qualification — supports moderate throughput demands
- Use Case — optimizes point-of-sale beverage preparation
Why Choose Cornelius 631100043 CB1522?
The Cornelius 631100043 CB1522 stands out among beverage dispensers with its heavy-duty stainless steel construction, five lever valves for precise beverage control, and ice cooling for reliable performance. Its drop-in design allows for straightforward installation, and its 60 lbs. ice capacity supports sustained service during peak hours. Enhanced sanitation with a built-in drip tray minimizes cleanup time, improving operational efficiency and product presentation compared to standard dispensers.
- Self-contained ice-cooled system for consistent beverage temperature
- Durable stainless steel body thrives in high-volume environments
- Drop-in installation with standard countertop cutout
- Five lever valves enable diverse beverage options
- Optimized for moderate-to-high throughput foodservice facilities
