Hobart HL800-1STD Legacy 80-Quart 4-Speed 3.0 HP All-Purpose Commercial Planetary Mixer With Stainless Steel Bowl, Beater, Dough Hook And Bowl Truck, 200-240 Volts, 3-phase

Item
#470046
MFG
#HL800-1STD
Specification Specifications
Ship Weight 1,375 lb
Manufacturer Hobart
Model Number HL800-1STD
Manufacturer Part # HL800-1STD
Type Planetary Mixers
Height 64 5/8 Inches
Width 27 1/4 Inches
Depth 60 3/16 Inches
Color Gray
Finish Metallic Gray Hybrid Powder-Coated
Capacity 80-Quart
Attachments Included Stainless Steel Bowl, Beater, Dough Hook And Bowl Truck
Orientation Floor
Features Variable Frequency Drive (VFD), Agitation Technology
NSF Listed Yes
UL Listed Yes
Hazardous Material No
Oversized Shipping No
Bowl Lift Type Power
Power Electric
Voltage 200-240
Hertz 50/60
Phase 3
Amps 12.0
Horsepower 3 HP
Hardwired Yes
Speed Range 27 - 322 RPM
Timer 50-minute SmartTimer With Automatic Time Recall
Speeds 4 Speeds Plus Stir
Transmission Type Gear-Driven
View all Specifications
Description

This Legacy unit features Shift-on-the-Fly controls that allow you to pulse and jog the mixer without needing to stop to change speeds.

The planetary mixer includes a 50-minute SmartTimer that includes Automatic Time Recall that remembers the last time setting for each speed, power bowl lift, and a stainless steel bowl guard.

The Legacy HL800-1STD planetary mixer is an electric unit that runs at 200-240 Volts, 50/60 Hertz, 3-phase, and 12.0 Amps for the 3.0 HP motor and it requires hardwiring. There is a hole at the top of the pedestal for a 3/4"-trade-size conduit. Hobart recommends that all electrical connections be made by qualified personnel who will follow all of the proper safety codes and guidelines.

This planetary mixer has a metallic gray hybrid powder coat finish and it is both UL listed and NSF listed. The unit stands firmly on neoprene footpads.

There is a Variable Frequency Drive (VFD) on this planetary mixer that uses an all-gear, direct-drive system to deliver precise mixing consistency while protecting and ensuring a long life for the motor.

The HL800-1STD is the Legacy 80-quart all-purpose commercial planetary mixer from Hobart with a stainless steel bowl, "B" beater, "ED" dough hook, and a bowl truck. The mixer features 4-speeds plus a stir speed using a heavy-duty, high-torque 3.0 HP motor and a gear-driven transmission.

The patented soft-start Agitation Technology on this planetary mixer gives a soft transition as mixing speeds increase to reduce splashing. There are 4 mixing speeds (Low 55 RPM, Medium-Low 96 RPM, Medium-High 183 RPM, and High 322 RPM) including a stir speed (Slow 27 RPM) on this mixer.

Hobart HL800-1STD Features

  • Stainless steel bowl
  • "B" Beater
  • "ED" Dough Hook
  • Bowl truck
  • Stainless steel bowl guard
  • Electrical specifications: 200-240 Volts, 50/60 Hertz, 3-phase, and 12.0 Amps for 3.0 HP
  • Hardwiring required
  • Neoprene footpads
  • Shift-on-the-Fly controls
  • 50-minute SmartTimer with Automatic Time Recall
  • Variable Frequency Drive (VFD) with all-gear, direct-drive system
  • Gear-driven transmission
  • Capacity: 80-quart
  • 4 mixing speeds (Low 55 RPM, Medium-Low 96 RPM, Medium-High 183 RPM, and High 322 RPM) including a stir speed (Slow 27 RPM)
  • Power bowl lift
  • Finish: Metallic gray hybrid powder coat finish
  • Color: Gray

Hobart HL800-1STD Benefits

  • Automatic Time Recall on SmartTimer remembers the last time setting for each speed
  • Precise mixing consistency with Variable Frequency Drive (VFD) that also protects the motor
  • Agitation Technology gives soft transition as mixing speeds increase to reduce splashing
  • Pulse and jog without stopping to change speeds with Shift-on-the-Fly controls
  • Heavy-duty, high-torque 3.0 HP motor
  • NSF listed
  • UL listed

Overall Dimensions:
Height: 64 5/8"
Width: 27 1/4"
Depth: 60 3/16"

Capacity: 80-quart

View all Description
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
NSF Listed
NSF Listed
This item meets the standards imposed by NSF International, which focuses on public safety, health, and the environment.
UL Listed
UL Listed
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL).
Hardwired
Hardwired
This product must be hardwired; it does not plug into a standard wall outlet.
Not For Residential Use
Not For Residential Use
Installed in a non-commercial setting will void your homeowner's insurance and the equipment manufacturer's warranty.
Free Shipping
Add this item to the cart to calculate your shipping rate
$39,503.00
Each
Contact Us for Details
Shipping
Lead time varies; contact our team with your ZIP code for more info.
  • Heavy-duty, high-torque 3.0 HP motor
  • Heavy-duty planetary mixer
  • 200-240/50/60/3-phase, 12.0 Amps
  • Hardwiring required
  • 4 mixing speeds
  • Automatic Time Recall on SmartTimer
  • Stainless steel bowl
  • "B" Beater
  • "ED" Dough Hook
  • Bowl truck
  • Agitation Technology gives soft transition as mixing speeds
  • Shift-on-the-Fly controls
  • UL & NSF listed
  • 80-quart capacity
  • Variable Frequency Drive (VFD) system
  • Power bowl lift
  • Warranty Info
    1 Year Limited Warranty
